Kilews SKD-BN500L series Brushless medium torque dc-type automatic Trigger start clutch type series

Name: Kilews SKD-BN500L series Brushless medium torque dc-type automatic Trigger start clutch type series
Brand: Kilews
SKU: SKD-BN500L series
Rating: 5 (10 reviews)

SKD-BN500L series Brushless medium torque dc-type automatic Trigger start clutch type series

Cikkszám: SKD-BN500L series

Adopts High-Functional Brushless Motor, marvelous lifespan and strong durability to repair and maintenance almost needless.

Válassz termékvariációt

Model:

SKD-BN512L SKD-BN512LF SKD-BN517LF SKD-BN519L

Mennyiség

A szállítási időt az ajánlatban pontosítjuk.

Közös adatok

Repeatable Torque Accuracy (%)	±3%
Power Controller	SKP-32BC-60W
Bit Type	B9.5、C

Modellek összehasonlítása

Model	Torque (kgf.cm)	Torque (Lbf.in)	Torque (N.m)	Free Speed (r.p.m) HI	Free Speed (r.p.m) LO	Screw Size Dia (mm) Machine Screw	Screw Size Dia (mm) Tapping Screw	Weight (g)	Length (mm)
SKD-BE203L	0.2~3.5	0.18~3.08	0.02~0.34	1000	700	1.0~2.3	1.0~2.0	330	LC:226 LB:240
SKD-BE203LS5	0.2~3.5	0.18~3.08	0.02~0.34	500	350	1.0~2.3	1.0~2.0	330	LC:226 LB:240
SKD-BE203LS6	0.2~3.5	0.18~3.08	0.02~0.34	370	260	1.0~2.3	1.0~2.0	330	LC:226 LB:240
SKD-BE203LS7	0.2~3.5	0.18~3.08	0.02~0.34	230	160	1.0~2.3	1.0~2.0	330	LC:226 LB:240
SKD-BE207L	0.5~7	0.44~6.16	0.05~0.69	1000	700	1.4~2.6	1.4~2.3	330	LC:226 LB:240
SKD-BE210L	1~10	0.88~8.8	0.10~0.98	1000	700	1.6~3.0	1.6~2.6	330	LC:226 LB:240
SKD-BE210P	2~10	1.76~8.8	0.2~0.98	1000	700	1.6~3.0	1.6~2.6	310	230

Features Adopts High-Functional Brushless Motor, marvelous lifespan and strong durability to repair and maintenance almost needless. Smaller size, light weight, low noise-pollution, fashionable design, high stability and easy operation motor which gives the benefit of longer working-time. (3 years warranty on motor) Brushless Motor has more stable torque output；It is the fit for operating in clean-room circumstance and no worry of pollution will be arisen. The tool to assemble Watch, laptop, digital Camera, DVD player, Cell phone, communication equipment and high tech products which need to be assembled in clean-room. CE and ETL are optional

Kilews SKD-BN500L series
Brushless medium torque dc-type automatic Trigger start clutch type series
