JBC SF Station
Automatic Solder-Wire Feeder
This Solder-Wire Feeder allows you to feed solder wire automatically from any position.
A szállítási időt az ajánlatban pontosítjuk.
| USB-B (front) | Firmware update and PC communications |
| Weight | up to 1 kg / 2.2 Ib |
| Diameter | max. 80 mm / 3.15 in |
| Height | max. 75 mm / 2.95 in |
| Reel stand axis | Ø 10 mm / Ø 0.4 in |
| Automatic Feed | 140 x 150 x 120 mm / 2.32 kg. , 5.51 x 5.91 x 4.72 in / 5.11 lb. |
| Package | 368 x 368 x 195 mm / 3.68 kg. , 14.49 x 14.49 x 7.68 in / 8.11 lb. |
This Solder-Wire Feeder allows you to feed solder wire automatically from any position. This station is supplied with GSF10V to feed solder wire of Ø 1 mm / 0.040 in and is furthermore compatible with solder wires from Ø 0.38 mm / 0.015 in up to Ø 1.8 mm / 0.073 in, using the respective Solder Wire Guide Kit. It features Solder Wire Perforation, allowing better flux flow and outgassing, thus avoiding projections and Foreign Object Debris (FOD). • 3 different working modes: Continuous Mode, Discontinuous Mode and Program Mode which allows configuration of dispensed wire speed and length Check out more information about features Automatic-Feed Stations.
- 📄 Dokumentum: manual-sf-auto-feeder-jbc-0028008_ID-217222_EN.pdf
