Robotphoenix BAT1000B-S60 Heavy Load Delta Robot
BAT1000B-S60
BAT1000B-S60 delta robot is a 2-axis parallel robot with a rated payload of 60kg, which has the characteristics of high speed and precision, small footprint and strong rated power. The delta industrial robot contributes to a flexible production during high precision and high speed manufacturing lines.
A szállítási időt az ajánlatban pontosítjuk.
Robot Model
BAT1000B-S60
Payload
60kg
Reach
1000mm
Axes
2
| Repeatability | 0.02mm |
| IP | IP54 |
BAT1000B-S60 delta robot is a 2-axis parallel robot with a rated payload of 60kg, which has the characteristics of high speed and precision, small footprint and strong rated power. The delta industrial robot contributes to a flexible production during high precision and high speed manufacturing lines.
Specifications
| Robot Model | BAT1000B-S60 |
| Rated Load | 60kg |
| Working Space Diameter | 1000mm |
| Number of Axles | 2 |
| Repeated Positioning Accuracy | 0.02mm |
| Repeated Positioning Accuracy of four Axis Angle (°) | / |
| Maximum Speed | 2m/s |
| Power Supply Voltage | three-phase AC380V±10％, 50/60HZ |
| Rated Power | 3.9KW |
| Protection Grade | IP54 |
| Weight | 185kg |
