Robotphoenix Mantis570-A3 6-Axis Robot
Mantis570-A3
Mantis series 570-A3 six-axis robot has a rated payload of 3kg. The 6 axis industrial robot is developed for complex applications with multiple degrees of freedom. It has graphical operation functions and is simple to program and use.
A szállítási időt az ajánlatban pontosítjuk.
Robot Model
Mantis570-A3
Payload
3kg
Reach
570mm
Axes
6
| Repeatability | 0.02mm |
| IP | IP54 |
Mantis series 570-A3 six-axis robot has a rated payload of 3kg. The 6 axis industrial robot is developed for complex applications with multiple degrees of freedom. It has graphical operation functions and is simple to program and use.
Specifications
| Robot Model | Mantis570-A3 | ||
| Load | 3kg | ||
| Working Radius | 570mm | ||
| Number of Axles | 6 | ||
| Motion | Axial Motion | Scope of Work | Maximum Speed |
| A1 Joint: Rotation of the First Mechanical Arm | -165°-+165° | 407°/s | |
| A2 Joint: Swing of the Second Mechanical Arm -130°-+103° | -110°-+110° | 407°/s | |
| A3 Joint: Swing of the Third Mechanical Arm -53°-+108° | -80°-+72° | 444°/s | |
| A4 Joint: Rotation of the Fourth Mechanical Arm | -160°-+160° | 444°/s | |
| A5 Joint: Swing of the Wrist Component -104°-+104° | -110°-+110° | 487°/s | |
| A6 Joint: Clamp End Rotation | -400°-+400° | 780°/s | |
| Integrated Signal Source | 12 Signals Are Set at the Wrist | ||
| Integrated Air Supply | 4-way Air (5bar) is Set at Wrist | ||
| Repetitive Positioning Accuracy | 0.02mm | ||
| Robot Installation | Table/Ceiling mounting | ||
| Degree of Protection | IP54 | ||
| Dimensions of Robot Base | 95mm×195mm | ||
| Robot Height | 1003mm | ||
| Weight | 32kg | ||
